- 4MP ( 2560 x 1440 ) full real time coding
- Max. resolution: 2560 x 1440
- H.264, H.265 and MJPEG encoding
- Support 4MP AHD / CVBS video access; 2MP TVI / AHD / CVBS video access
- Micro SD card local storage of image and record with pre-alarm recording and auto cycle recording
- Smart analysis including line crossing, intrusion, exception detection ( optional )
- PoE / DC12V power supply
- 1 CH alarm input and 1 CH alarm output
- Support three streams
- COC control
- Support ROI coding
- TVS 6000V lightning protection, surge protection
| Video & Audio Input | |
| HD Analog Video Input |
1 CH, BNC interface ( level : 1.0Vp-p, impedance : 75Ω ), PAL / NTSC selfadaptive, 4MP AHD /CVBS video access; 2MP TVI/AHD/CVBS video access |
| Audio Input | 1 CH : 3.5 mm interface, share with MIC IN interface |
| Video & Audio Encoding Parameters | |
| Video Compression | H.264, H.265, MJPEG |
| H.264 Compression Standard |
Baseline Profile / Main Profile / High Profile |
| Bit Rate Type | VBR / CBR |
| Quality | Five levels under VBR; Freely adjustable under CBR |
| Bit Rate | 32Kbps ~ 16Mbps |
| Resolution | 4MP ( 2560×1440 ), 3MP ( 2304×1296 ) / ( 2048×1536 ), 1080P ( 1920×1080 ), 960P ( 1280×960 ), 720P ( 1280×720 ), D1, CIF, 480×240 |
| Multi-streams | 4MP ( 1~30fps ) / 3MP ( 1~30fps ) / 1920×1080 ( 1~30fps ) / 960P ( 1~30fps ) / 720P ( 1~30fps ) 720P ( 1~30fps ) / D1 ( 1~30fps ) / CIF ( 1~30fps ) D1 ( 1~30fps ) / 480×240 ( 1~30fps ) / CIF ( 1~30fps ) |
| Audio Compression | G711A / U |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
| ROI | Yes |
| Interfaces | |
| Network | RJ45 |
| Audio | MIC IN × 1, SPK OUT × 1 |
| Storage Card | Up to 128GB |
| RS485 | Yes |
| Alarm Input | 1 CH alarm input |
| Alarm Output | 1 CH alarm output |
| Local Output | 1 CH BNC output |
| Functions | |
| Remote Monitoring | IE browsing, CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 6 users; Support multi-stream real time transmission |
| Network Protocol | TCP / IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP |
| Interface Protocol | ONVIF, GB-T / 28181-2011 |
| Image Snap | JPEG encoding, image quality adjustable |
| Smart Analysis | Exception detection, intrusion detection, line crossing detection |
| Ingress Protection | TVS6000V lightning protection, surge protection |
| Others | |
| Power Supply | PoE / DC12V |
| Power Output | Max 12V@0.5A |
| Power Consumption | < 4W |
| Operating Environment |
-20℃ ~ 55℃, 10% ~ 90% ( relative humidity ) |
| Dimensions ( mm ) | 140 × 74.3 × 29 ( W × D × H ) |
| Weight ( net ) | 220g |
| Installation | Wall mounting |
